KNIPEX 97 49 05 – Die Set

KNIPEX 97 49 05 – Die Set for Non-Insulated Open Plug Connectors (4.8 + 6.3 mm)

Precision die set for crimping non-insulated open plug type connectors with plug widths of 4.8 mm and 6.3 mm. Ideal for reliable electrical connections in automotive and industrial applications. Compatible with KNIPEX locator 97 49 95 for guided crimping.

Key Specs:

• Application: Non-insulated open lug connectors

• Plug widths: 4.8 mm and 6.3 mm
• Crimping capacity:
  • 0.5 – 1.0 mm²
  • 1.5 – 2.5 mm²
  • 4.0 – 6.0 mm²
• Number of crimp profiles: 3
• AWG: 20 – 10
• Not compatible with special contact systems (e.g. Tyco, Molex)
• Weight: 46 g
• Dimensions: 50 x 10 mm
• REACH compliant: Does not contain SVHC
• RoHS compliant: Not applicable
• Article No.: 97 49 05
• EAN: 4003773030867
