KNIPEX 97 49 04 – Die Set

KNIPEX 97 49 04 – Die Set for Non-Insulated Open Plug Connectors (2.8 mm + 4.8 mm)

The KNIPEX 97 49 04 is a precision die set designed for crimping non-insulated, open plug type connectors with plug widths of 2.8 mm and 4.8 mm. Ideal for use in electrical applications, this die set offers reliable performance for a wide range of wire sizes.

Key Features:

• Designed for non-insulated open lug connectors
• Four crimping profiles for wire sizes:
  • 0.1 – 0.25 mm² (plug width 2.8 mm)
  • 0.5 – 1.0 mm² (plug width 2.8 mm)
  • 0.5 – 1.0 mm² (plug width 4.8 mm)
  • 1.5 – 2.5 mm² (plug width 4.8 mm)
• Compatible with locator 97 49 94 for precise alignment during crimping
• Not suitable for special contact series (Tyco, Molex, JST, etc.)

Specifications:

• Crimping capacity: 0.1 – 2.5 mm²
• AWG: 26 – 14
• Number of crimp profiles: 4
• Dimensions: 50 x 10 mm
• Weight: 42 g
• Article Number: 97 49 04
• EAN: 4003773030850
• REACH compliant: Yes (no SVHC)
• RoHS compliant: Not applicable
