KNIPEX 77 02 130 Electronics Diagonal Cutter

KNIPEX 77 02 130 Electronics Diagonal Cutter – Precision Cutting with Box Joint Design

The KNIPEX 77 02 130 Electronics Diagonal Cutter is engineered for high-precision electronics work where accuracy and reliability are critical. Thanks to its backlash-free box joint and high transmission ratio, this compact cutter delivers smooth, controlled cuts with minimal effort — perfect for circuit board assembly, fine wires, and delicate components.

Key Features:

• Backlash-Free Box Joint: Durable forged design ensures consistent, long-lasting cutting precision.
• High Transmission Ratio: Requires less handforce while delivering maximum cutting power.
• Precision Handling: Slim sleeves allow easy, comfortable control between thumb and index finger.
• Smooth Operation: Low-friction double spring provides consistent, even opening for fatigue-free use.
• Corrosion Protection: Mirror-polished head with fine oil film protects against rust without chrome plating — preventing flaking or contamination of sensitive components.
• Laser-Hardened Cutting Edges: Extremely durable cutting edges, hardened to at least 62 HRC, ensure long tool life even in continuous professional use.
• Compact Round Head Design: Small bevel allows flush cuts even in tight spaces.

Cutting Capacities:

• Soft wire: Ø 0.2 – 2.0 mm
• Medium-hard wire: Ø 1.5 mm
• Hard wire: Ø 0.8 mm

Technical Specifications:

• Article No.: 77 02 130
• EAN: 4003773039341
• Head Finish: Mirror polished
• Handles: Multi-component grips
• Weight: 81 g
• Dimensions: 130 x 70 x 16 mm
• Jaw Length (B): 16.2 mm
• Jaw Thickness (Joint, D): 8.5 mm
• Head Width (A): 13 mm
• Cutting Edge Length (C): 16.2 mm
• Standard: DIN ISO 9654
• Compliance: REACH compliant (no SVHC), RoHS not applicable

Trusted by electronics professionals for its precision, durability, and comfort.
